Series HERMES-J HERMES-J MUSE-D PHANES-K
Capacity 4GB~32GB 4GB~128GB 8GB~128GB 32GB~64GB
Form-Factor mSATA mini form factor Compliant with JEDEC MO-300B mSATA mini form factor Compliant with JEDEC MO-300B mSATA mini form factor Compliant with JEDEC MO-300B mSATA mini form factor Compliant with JEDEC MO-300B
Compatibility SATA Revision 3.1
ATA-8 command set
SATA Revision 3.1
ATA-8 command set
SATA Revision 3.1
ATA-8 command set
SATA Revision 3.2
ATA-8 ACS4 command set
Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s
Sequential read (Max.) 220 MB/sec 230.9 MB/sec 533 MB/sec 550 MB/sec
Sequential write (Max.) 110 MB/sec 79.4 MB/sec 125 MB/sec 255 MB/sec
Operating temp. (STD/IND or WIDE) S : 0˚C~+70˚C/
I : -40˚C~+85˚C
S : 0˚C~+70˚C/
W : -40˚C~+85˚C
S : 0˚C~+70˚C/
W : -40˚C~+85˚C
S : 0˚C~+70˚C/
W : -40˚C~+85˚C
Power requirement +3.3 V ± 5% +3.3 V ± 5% +3.3 V ± 5% +3.3 V ± 5%
Wear-leveling Static Static Static Static and Dynamic
TBW Up to 192 TBW at 32GB Up to 38.4 TBW at 128GB Up to 210.5 TBW at 128GB Up to 42 TBW at 64GB
Erase counts 60,000 3,000 3,000 3,000
Weight (Max.) 3.5g 3.5g 3.5g 3.5g
Dimension (WxLxH,mm) 29.85 x 26.80 29.85 x 26.80 29.85 x 26.80 29.85 x 26.80
Conformal coating Optional Optional Optional Optional
Warranty (Std./Ind.) 3/5 years or within 60,000 erasing counts 2 years or within 3,000 erasing counts 2 years or within 3,000 erasing counts 2 years or within 3,000 erasing counts
Series HERMES-J
Capacity 4GB~32GB
Form-Factor mSATA mini form factor Compliant with JEDEC MO-300B
Compatibility SATA Revision 3.1
ATA-8 command set
Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s
Sequential read (Max.) 220 MB/sec
Sequential write (Max.) 110 MB/sec
Operating temp. (STD/IND or WIDE) S : 0˚C~+70˚C/
I : -40˚C~+85˚C
Power requirement +3.3 V ± 5%
Wear-leveling Static
TBW Up to 192 TBW at 32GB
Erase counts 60,000
Weight (Max.) 3.5g
Dimension (WxLxH,mm) 29.85 x 26.80
Conformal coating Optional
Warranty (Std./Ind.) 3/5 years or within 60,000 erasing counts
Series HERMES-J MUSE-D
Capacity 4GB~128GB 8GB~128GB
Form-Factor mSATA mini form factor Compliant with JEDEC MO-300B mSATA mini form factor Compliant with JEDEC MO-300B
Compatibility SATA Revision 3.1
ATA-8 command set
SATA Revision 3.1
ATA-8 command set
Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s
Sequential read (Max.) 230.9 MB/sec 533 MB/sec
Sequential write (Max.) 79.4 MB/sec 125 MB/sec
Operating temp. (STD/IND or WIDE) S : 0˚C~+70˚C/
W : -40˚C~+85˚C
S : 0˚C~+70˚C/
W : -40˚C~+85˚C
Power requirement +3.3 V ± 5% +3.3 V ± 5%
Wear-leveling Static Static
TBW Up to 38.4 TBW at 128GB Up to 210.5 TBW at 128GB
Erase counts 3,000 3,000
Weight (Max.) 3.5g 3.5g
Dimension (WxLxH,mm) 29.85 x 26.80 29.85 x 26.80
Conformal coating Optional Optional
Warranty (Std./Ind.) 2 years or within 3,000 erasing counts 2 years or within 3,000 erasing counts
Series PHANES-K
Capacity 32GB~64GB
Form-Factor mSATA mini form factor Compliant with JEDEC MO-300B
Compatibility SATA Revision 3.2
ATA-8 ACS4 command set
Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s
Sequential read (Max.) 550 MB/sec
Sequential write (Max.) 255 MB/sec
Operating temp. (STD/IND or WIDE) S : 0˚C~+70˚C/
W : -40˚C~+85˚C
Power requirement +3.3 V ± 5%
Wear-leveling Static and Dynamic
TBW Up to 42 TBW at 64GB
Erase counts 3,000
Weight (Max.) 3.5g
Dimension (WxLxH,mm) 29.85 x 26.80
Conformal coating Optional
Warranty (Std./Ind.) 2 years or within 3,000 erasing counts
Series HERMES-J HERMES-J MUSE-D PHANES-K
SpecSheet Downloads Downloads Downloads Downloads
DataSheet Downloads Downloads Downloads Downloads
Dimension Downloads Downloads Downloads Downloads
