Series PHANES-F PHANES-F PHANES-F PHANES-P PHANES-P PHANES-P
Capacity 1GB~4GB 8GB~64GB (Kioxia)
8GB~32GB (Samsung)
4GB~32GB (Kioxia)
4GB~16GB (Samsung)
16GB~256GB
(Kioxia)
32GB~128GB
(Micron B16)
4GB~64GB
Form-Factor Standard microSD Standard microSD Standard microSD Standard microSD Standard microSD Standard microSD
Compatibility SD3.0 SD3.0 SD3.0 SD6.1 SD6.1 SD6.1
microSD/microSDHC 1GB to 2GB: FAT file system 8GB to 32GB: FAT16 file system 1GB to 2GB: FAT file system 16GB / 32GB:
FAT16 file system
32GB:
FAT16 file system
4GB~32GB:
FAT16 file system
microSDHC/microSDXC 4GB: FAT16 file system 64GB: exFAT file system 4GB: FAT16 file system 64GB~256GB: exFAT 64GB~128GB: exFAT 64GB: exFAT file system
Data transfer rate Class-10 Class-10 Class-10 A1,V10,Class-10
U1,UHS-1
A1,V10,Class-10
U1,UHS-1
A1,V10,Class-10
U3,UHS-1
Sequential read (Max.) microSD: 23.4 MB/sec
microSDHC: 67.2 MB/sec
microSDHC: 93.9 MB/sec
microSDXC: 94.3 MB/sec
microSDHC: 95.3 MB/sec microSDHC: 95.0 MB/sec
microSDXC: 95.0 MB/sec
microSDHC: 95.0 MB/sec
microSDXC: 95.0 MB/sec
microSDHC: 95.0 MB/sec
microSDXC: 95.0 MB/sec
Sequential write (Max.) microSD: 20.7 MB/sec
microSDHC: 48.4 MB/sec
microSDHC: 61.6 MB/s (Max.)
microSDXC: 76.7 MB/s (Max.)
microSDHC: 83.6 MB/sec microSDHC: 20.0 MB/sec
microSDHC: 30.0 MB/sec
microSDHC: 15.0 MB/sec
microSDHC: 55.0 MB/sec
microSDHC: 85.0 MB/sec
microSDHC: 85.0 MB/sec
Operating temp.
(STD/IND or WIDE)
I : -40˚C~+85˚C W : -40˚C~+85˚C W : -40˚C~+85˚C W : -25˚C~+85˚C W : -25˚C~+85˚C W : -25˚C~+85˚C
Power requirement 3.3V ± 10% 3.3V ± 10% 3.3V ± 10% 3.3V ± 10% 3.3V ± 10% 3.3V ± 10%
Wear-leveling Static & Dynamic Static & Dynamic Static & Dynamic Static & Dynamic Static & Dynamic Static & Dynamic
Erase counts 60,000 3,000 20,000 3,000 3,000 30,000
Weight (Max.) 0.3g 0.3g 0.3g 0.3g 0.3g 0.3g
Dimension (WxLxH,mm) 11.0 x 15. 0 x 1.0 11.0 x 15. 0 x 1.0 11.0 x 15. 0 x 1.0 11.0 x 15. 0 x 1.0 11.0 x 15. 0 x 1.0 11.0 x 15. 0 x 1.0
Warranty (Std./Ind.) 5 years or within 60,000 erasing counts 2 years or within 3,000 erasing counts 2 years or within 20,000 erasing counts 2 years or within 3,000 erasing counts 2 years or within 3,000 erasing counts 2 years or within 30,000 erasing counts
Series PHANES-F
Capacity 1GB~4GB
Form-Factor Standard microSD
Compatibility SD3.0
microSD/microSDHC 1GB to 2GB: FAT file system
microSDHC/microSDXC 4GB: FAT16 file system
Data transfer rate Class-10
Sequential read (Max.) microSD: 23.4 MB/sec
microSDHC: 67.2 MB/sec
Sequential write (Max.) microSD: 20.7 MB/sec
microSDHC: 48.4 MB/sec
Operating temp.
(STD/IND or WIDE)
I : -40˚C~+85˚C
Power requirement 3.3V ± 10%
Wear-leveling Static & Dynamic
Erase counts 60,000
Weight (Max.) 0.3g
Dimension (WxLxH,mm) 11.0 x 15. 0 x 1.0
Warranty (Std./Ind.) 5 years or within 60,000 erasing counts
Series PHANES-F
Capacity 8GB~64GB (Kioxia)
8GB~32GB (Samsung)
Form-Factor Standard microSD
Compatibility SD3.0
microSD/microSDHC 8GB to 32GB: FAT16 file system
microSDHC/microSDXC 64GB : exFAT
Data transfer rate Class-10
Sequential read (Max.) microSDHC: 93.9 MB/sec
microSDXC: 94.3 MB/sec
Sequential write (Max.) microSDHC: 61.6 MB/s (Max.)
microSDXC: 76.7 MB/s (Max.)
Operating temp.
(STD/IND or WIDE)
W : -40˚C~+85˚C
Power requirement 3.3V ± 10%
Wear-leveling Static & Dynamic
Erase counts 3,000
Weight (Max.) 0.3g
Dimension (WxLxH,mm) 11.0 x 15. 0 x 1.0
Warranty (Std./Ind.) 2 years or within 3,000 erasing counts
Series PHANES-F
Capacity 4GB~32GB (Kioxia)
4GB~16GB (Samsung)
Form-Factor Standard microSD
Compatibility SD3.0
microSD/microSDHC 1GB to 2GB: FAT file system
microSDHC/microSDXC 4GB: FAT16 file system
Data transfer rate Class-10
Sequential read (Max.) microSDHC: 95.3 MB/sec
Sequential write (Max.) microSDHC: 83.6 MB/sec
Operating temp.
(STD/IND or WIDE)
W : -40˚C~+85˚C
Power requirement 3.3V ± 10%
Wear-leveling Static & Dynamic
Erase counts 20,000
Weight (Max.) 0.3g
Dimension (WxLxH,mm) 11.0 x 15. 0 x 1.0
Warranty (Std./Ind.) 2 years or within 20,000 erasing counts
Series PHANES-P PHANES-P
Capacity 16GB~256GB (Kioxia) 32GB~128GB (Micron B16)
Form-Factor Standard microSD Standard microSD
Compatibility SD6.1 SD6.1
microSD/microSDHC 16GB / 32GB:
FAT16 file system
16GB:
FAT16 file system
microSDXC 64GB~256GB:
exFAT file system
128GB~256GB:
exFAT file system
Data transfer rate A1,V10,Class-10,
U1,UHS-1
A1,V10,Class-10,
U1,UHS-1
Sequential read (Max.) microSDHC: 95.0 MB/sec
microSDXC: 95.0 MB/sec
microSDHC: 95.0 MB/sec
microSDXC: 95.0 MB/sec
Sequential write (Max.) >microSDHC: 20.0 MB/sec
microSDXC: 30.0 MB/sec
>microSDHC: 15.0 MB/sec
microSDXC: 50.0 MB/sec
Operating temp.
(STD/IND or WIDE)
W : -25˚C~+85˚C W : -25˚C~+85˚C
Power requirement 3.3V ± 10% 3.3V ± 10%
Wear-leveling Static & Dynamic Static & Dynamic
Erase counts 3,000 3,000
Weight (Max.) 0.3g 0.3g
Dimension (WxLxH,mm) 11.0 x 15. 0 x 1.0 11.0 x 15. 0 x 1.0
Warranty (Std./Ind.) 2 years or within 3,000 erasing counts 2 years or within 3,000 erasing counts
Series PHANES-P
Capacity 4GB~64GB (Kioxia)
Form-Factor Standard microSD
Compatibility SD6.1
microSD/microSDHC 4GB~32GB:
FAT16 file system
microSDXC 64GB:
exFAT file system
Data transfer rate A1,V10,Class-10,
U1,UHS-1
Sequential read (Max.) microSDHC: 95.0 MB/sec
microSDXC: 95.0 MB/sec
Sequential write (Max.) >microSDHC: 85.0 MB/sec
microSDXC: 85.0 MB/sec
Operating temp.
(STD/IND or WIDE)
W : -25˚C~+85˚C
Power requirement 3.3V ± 10%
Wear-leveling Static & Dynamic
Erase counts 30,000
Weight (Max.) 0.3g
Dimension (WxLxH,mm) 11.0 x 15. 0 x 1.0
Warranty (Std./Ind.) 2 years or within 30,000 erasing counts
Series PHANES-F PHANES-F PHANES-F PHANES-P (Kioxia) PHANES-P (Micron B16) PHANES-P (Kioxia)
SpecSheet Downloads Downloads Downloads Not Available Not Available Not Available
DataSheet Downloads Downloads Downloads Downloads Downloads Downloads
Dimension Downloads Downloads Downloads Downloads Downloads Downloads
