| Flash Type | SLC | MLC |
|---|---|---|
| Flash Process | Kioxia 24nm | Kioxia 15nm |
| Series | PHANES-D (G5) | PHANES-D (G5) |
| Picture |  |
|
| Capacity | 128MB~8GB | 8GB~32GB |
| Form-Factor | Pen drive | Pen drive |
| Compatibility | USB 3.0 | USB 3.0 |
| Data transfer rate | FullSpeed, HighSpeed and SuperSpeed | FullSpeed, HighSpeed and SuperSpeed |
| Sequential read (Max.) | 41.0 MB/sec | 98.0 MB/sec |
| Sequential write (Max.) | 36.6 MB/sec | 51.2 MB/sec |
| Operating temp. (STD/IND or WIDE) |
S : 0˚C~+70˚C/ W : -40˚C~+85˚C |
S : 0˚C~+70˚C/ W : -40˚C~+85˚C |
| OS supported | Windows series O.S.Linux, VxWorks and DOS | Windows series O.S.Linux, VxWorks and DOS |
| Power requirement | 5V ± 10% via USB port | 5V ± 10% via USB port |
| Wear-leveling | Global | Global |
| TBW | Up to (TBC) TBW at 8GB | Up to (TBC) TBW at 32GB |
| Erase counts | 60,000 | 3,000 |
| Weight (Max.) | 10g | 10g |
| Dimension (WxLxH,mm) | 17.20 x 47.20 x 7.80 | 17.20 x 47.20 x 7.80 |
| Conformal coating | Optional | Optional |
| Warranty (Std./Ind.) | 3/5 years or within 60,000 erasing counts | 2 years or within 3,000 erasing counts |
| Flash Type | SLC |
|---|---|
| Flash Process | Kioxia 24nm |
| Series | PHANES-D (G5) |
| Picture | |
| Capacity | 128MB~8GB |
| Form-Factor | Pen drive |
| Compatibility | USB 3.0 |
| Data transfer rate | FullSpeed, HighSpeed and SuperSpeed |
| Sequential read (Max.) | 41.0 MB/sec |
| Sequential write (Max.) | 36.6 MB/sec |
| Operating temp. (STD/IND or WIDE) |
S : 0˚C~+70˚C/ I : -40˚C~+85˚C |
| OS supported | Windows series O.S.Linux, VxWorks and DOS |
| Power requirement | 5V ± 10% via USB port |
| Wear-leveling | Global |
| TBW | Up to (TBC) TBW at 8GB |
| Erase counts | 60,000 |
| Weight (Max.) | 10g |
| Dimension (WxLxH,mm) | 17.20 x 47.20 x 7.80 |
| Conformal coating | Optional |
| Warranty (Std./Ind.) | 3/5 years or within 60,000 erasing counts |
| Flash Type | MLC |
|---|---|
| Flash Process | Kioxia 15nm |
| Series | PHANES-D (G5) |
| Picture | |
| Capacity | 8GB~32GB |
| Form-Factor | Pen drive |
| Compatibility | USB 3.0 |
| Data transfer rate | FullSpeed, HighSpeed and SuperSpeed |
| Sequential read (Max.) | 98.0 MB/sec |
| Sequential write (Max.) | 51.2 MB/sec |
| Operating temp. (STD/IND or WIDE) |
S : 0˚C~+70˚C/ W : -40˚C~+85˚C |
| OS supported | Windows series O.S.Linux, VxWorks and DOS |
| Power requirement | 5V ± 10% via USB port |
| Wear-leveling | Global |
| TBW | Up to (TBC) TBW at 32GB |
| Erase counts | 3,000 |
| Weight (Max.) | 10g |
| Dimension (WxLxH,mm) | 17.20 x 47.20 x 7.80 |
| Conformal coating | Optional |
| Warranty (Std./Ind.) | 2 years or within 3,000 erasing counts |
| Flash Type | SLC | MLC |
|---|---|---|
| Series | PHANES-D (G5) | PHANES-D (G5) |
| Picture | |
|
| SpecSheet |
|
|
| DataSheet |
|
|
| Dimension |
|
|
