A19058 HERMES-JI Series MLC 1.8” Slim Lite SATA III SSD (8SJ)

 Features

 MLC-NAND flash technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support S.M.A.R.T. command set and utility
 Support Power Loss Protection
 Capacities from 4GB up to 256GB
 Specification
 Compatibility SATA Revision 3.1  Power consumption
SLC  Declarations ATA-8 command set  Power requirement +5 V ± 5%
306mA (Max.)
RoHS & REACH compliant
Reading mode

 Flash technology MLC-NAND flash technology  Writing mode 280mA (Max.)
 Form-factor 1.8" Slim Lite SATA III SSD JEDEC  Idle mode 151mA (Max.)
MO-297A Specification compliance  Reliability
 Host Interface SATA 7-pin (data) + 15-pin (power)  Wear-leveling Static wear-leveling algorithms
 Performance  TBW Up to 75 TBW at 256GB Capacity
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s (Client workload by JESD-219A)
aSLC  Sequential read 420 MB/sec (Max.)  Erase counts Up to 3,000 times
Sequential write

ECC
140 MB/sec (Max.)
40 bits per 1024 bytes block

Physical specification


Environmental
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Weight (Max.) 15g
 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Dimension (WxL) 54.00 x 39.00 (mm)
 Humidity 10% ~ 95% non-condensing  Conformal coating Optional
 Vibration 70 Hz to 2K Hz, 20G, 3 axes  Warranty 2 years or within 3,000 erasing counts
 Shock 0.5ms, 1500 G, 3 axes
70,000 feet
Altitude

MLC  Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
4GB SB8SJ004G-JJCTMB-(T) 4GB WB8SJ004G-JJCTMB-(T)C
8GB SB8SJ008G-JJCTMB-(T) 16GB WB8SJ008G-JJCTMB-(T)C
8GB
16GB
SB8SJ016G-JJCTMB-(T)
WB8SJ016G-JJCTMB-(T)C
3D-NAND 128GB SB8SJ032G-JJCTMB-(T) 128GB WB8SJ032G-JJCTMB-(T)C
32GB
32GB
64GB
SB8SJ064G-JICTMB-(T)
64GB
WB8SJ064G-JICTMB-(T)C
WB8SJ128G-JICTMB-(T)C
SB8SJ128G-JICTMB-(T)
SB8SJ256G-JICTMB-(T)
WB8SJ256G-JICTMB-(T)C
256GB
256GB
Notes : HERMES-J Series from 4GB to 32GB; HERMES-I Series from 64GB and 256GB
 Part Number Decoder X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X4
X3
X2
X1
DRAM Module Example 1 8 S J 0 3 2 G J J C T M B T C
B
W
Example 2
W B 8 S J 2 5 6 G J I C T M B T C
Adapter S : Standard grade operating temp. 0ºC~+70ºC C : Commercial grade
Controller grade
X13
Grade
X1
W : Wide temp. grade operating temp. -40ºC~+85ºC
X14
Flash IC brand
X2
The material of casing
T : Toshiba NAND flash IC
B : Bare (without casing)
X15 Flash IC type
Card-drive 8SJ : 1.8” Slim Lite SATA III SSD Capacity B : Toshiba 15nm MLC
Product category
X3
X4
X5
M : MLC-NAND flash IC
MLC Technology
X16
X6
X7
X8
X9
064G : 64GB
004G : 4GB
X19
X18
Reserved for specific requirements
X20
008G : 8GB
016G : 16GB 128G : 128GB Blank : Standard product w/o thermal sensor and conformal-coating
256G : 256GB
032G : 32GB T : Thermal Sensor (optional)
X11 Controller C : Conformal coating (optional)
J : HERMES Series
X12 Controller version
A, B, C, D…..I,J...
79
