Page 82 - APRO_2020_Catalog

A19055 MUSE-D Series MLC mSATA III Half Size SSD (MSH)

 Features
 MLC-NAND flash technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm.
 Support S.M.A.R.T. command set and utility
 Ultra-high random read/write speed
 Capacities from 8GB up to 128GB
 Specification
 Compatibility SATA Revision 3.1  Altitude 70,000 feet
SLC  Declarations ATA-8 command set  Power consumption +3.3 V ± 5%

RoHS & REACH compliant
Power requirement
 Flash technology MLC-NAND flash technology  Reading mode 130mA (Max.)
 Form-factor mSATA mini form factor  Writing mode 200mA (Max.)
Compliant with JEDEC MO-300B  Idle mode 80mA (Max.)
 Host Interface mini PCI-e connector with 52 pins SATA pin out  Reliability
 Performance  Wear-leveling Static wear-leveling algorithms
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s  TBW Up to 210.5 TBW at 128GB Capacity
aSLC  Sequential read 533 MB/sec (Max.)  Erase counts (Client workload by JESD-219A)
Up to 3,000 times
125 MB/sec (Max.)
Sequential write

4KB random read

30K IOPS (Max.)
ECC

LDPC (Low Density Parity Check)
 4KB random write 26K IOPS (Max.)  Physical specification
 Environmental  Weight (Max.) 3.5g
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Dimension (WxL) 29.85 x 26.80 (mm)
 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Conformal coating Optional
 Humidity 10% ~ 95% non-condensing  Warranty 2 years or within 3,000 erasing counts
Vibration
70 Hz to 2K Hz, 20G, 3 axes

MLC  Shock 0.5ms, 1500 G, 3 axes
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
8GB SBMSH008G-VDCTM-(T) 16GB WBMSH008G-VDCTM-(T)C
8GB
WBMSH016G-VDCTM-(T)C
16GB
SBMSH016G-VDCTM-(T)
3D-NAND 128GB SBMSH032G-VDCTM-(T) 128GB WBMSH032G-VDCTM-(T)C
32GB
32GB
SBMSH064G-VDCTM-(T)
64GB
64GB
WBMSH064G-VDCTM-(T)C
SBMSH128G-VDCTM-(T)
WBMSH128G-VDCTM-(T)C

X1 Part Number Decoder X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X4
X3
X2
Example
DRAM Module W Grade M S H 1 2 8 G X12 Controller version T M T C
B
V
C
D
X1
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..
W : Wide temp. grade operating temp. -40ºC~+85ºC
X13 Controller grade
X2 The material of casing C : Commercial grade
Adapter B : Bare (without casing) T : Toshiba NAND flash IC
Flash IC brand
X14
Product category
X4
X5
X3
MSH : Mini SATA Module Half Size (mSATA mini)
X6 X7 X8 X9 Capacity X15 Flash IC type
M : MLC-NAND flash IC X20 Reserved for specific requirements
064G : 64GB
008G : 8GB
Card-drive 016G : 16GB 128G : 128GB Blank : Standard product w/o thermal sensor and conformal-coating
X17
X19
X18
032G : 32GB
T : Thermal Sensor (optional)
Controller
X11
C : Conformal coating (optional)
V : MUSE Series
75
Product specifications are subject to change without prior notice.
