A19018 PHANES-K Series Industrial SLC 2.5” 7mm Height SATA III SSD (7SF)

 Features
 SLC-NAND flash technology
 Optional thermal sensor to monitor SSD operating temperature
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm
 Support S.M.A.R.T. command set and utility
 Support Power Loss Protection
 Capacities from 8GB up to 128GB
 Specification
 Compatibility SATA Revision 3.2  Power requirement +5V ± 5%
SLC  Declarations ATA-8 ACS4 command set  Reading mode 1,700 mW (Max.)
Writing mode
2,300 mW (Max.)
RoHS & REACH compliant

 Flash technology SLC-NAND flash technology  Idle mode 315 mW (Max.)
 Form-factor Rugged Metal 2.5” 7mm height SATA SSD  Reliability
 Host Interface SATA 7-pin (data) + 15-pin (power)  Wear-leveling Static and Dynamic wear-leveling algorithms
 Performance  TBW Up to 2,133 TBW at 128GB Capacity
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s (Client workload by JESD-219A)
 Sequential read 480 MB/sec (Max.)  MTBF > 3,000,000 hours
aSLC  Sequential write 425 MB/sec (Max.)  Erase counts Up to 60,000 times

LDPC (Low Density Parity Check)

Environmental
ECC
Operating temp.
STD. 0˚C~+70˚C/IND. -40˚C~+85˚C
Physical specification


 Non-operating temp. STD. -20˚C~+80˚C/IND. -50˚C~+95˚C  Weight (Max.) 50g
 Humidity 10% ~ 95% non-condensing  Dimension (WxLxH) 69.90 x 100.00 x 7.00 (mm)
 Vibration 80 Hz to 2K Hz, 20G, 3axes  Conformal coating Optional
 Shock 0.5ms, 1500G, 3 axes  Warranty
 Altitude 70,000 feet  SLC STD. grade 3 years or within 60,000 erasing counts
SLC IND. grade
Power consumption


5 years or within 60,000 erasing counts
MLC  Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
8GB SR7SF008G-PKCTC-(T) 8GB WR7SF008G-PKITI-(T)
16GB SR7SF016G-PKCTC-(T) 16GB WR7SF016G-PKITI-(T)
WR7SF032G-PKITI-(T)
SR7SF032G-PKCTC-(T)
32GB
32GB
3D-NAND  Part Number Decoder SR7SF064G-PKCTC-(T) 128GB WR7SF064G-PKITI-(T)
64GB
64GB
SR7SF128G-PKCTC-(T)
WR7SF128G-PKITI-(T)
128GB
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example R 7 S F 1 2 8 G P K I T I T C
W
DRAM Module X1 Grade X12 Controller version
S : Standard grade operating temp. 0ºC~+70ºC
W: Industrial grade operating temp. -40ºC~+85ºC A, B, C, D…..
X13 Controller grade
X2 The material of casing
C : Commercial grade
Adapter 7SF : 2.5” 7 mm height SATA III SSD T : Toshiba SLC-NAND flash IC
R : Rugged metal casing
I : Industrial grade
Flash IC brand
X4
X5
Product category
X3
X14
Capacity
Flash IC grade
X6
X7
X9
X15
008G : 8GB X8 064G : 64GB C : Commercial grade
I : Industrial grade
016G : 16GB
128G : 128GB
Card-drive P : PHANES Series Blank : Standard product w/o thermal sensor and conformal-coating
032G : 32GB
X19
X20
Reserved for specific requirements
X17
X18
Controller
X11
T : Thermal Sensor (optional)
C : Conformal coating (optional)
35
Product specifications are subject to change without prior notice.
