A19023     BON-III Series   Industrial SLC 2.5” 9mm Height SATA III SSD Supports FE/SE, w/DRAM (2SR-FE/SE)

                                                               Features
                                                                SLC-NAND flash technology
                                                                Support power protection via Tantalum Capacitors
                                                                Support Trim command set
                                                                Support Native Command Queuing (NCQ)
                                                                Support Fast Erase and Secure Erase Functions
                                                                Support Full-Drive Encryption
                                                                S.M.A.R.T. command set
                                                                Capacities from 8GB up to 256GB
               Specification
               Compatibility    SATA Revision 3.1              Power consumption
                                 ATA-8 ACS2 command set         Power requirement  +5V ± 5%
               Declarations     RoHS & REACH compliant         Reading mode    350 mA (Max.)                      SLC
               Flash technology  SLC-NAND flash technology      Writing mode    420 mA (Max.)
               Form-factor      Rugged Metal 2.5” 9mm height SATA SSD    Idle mode  120 mA (Max.)
               Host Interface   SATA 7-pin (data) + 15-pin (power)    Reliability
               Performance                                     Wear-leveling   Global wear-leveling algorithms
               Data transfer rate  SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s    TBW       Up to 1,807.4 TBW at 256GB Capacity
               Sequential read  173.4 MB/sec (Max.)                             (Client workload by JESD-219A)
               Sequential write  165.8 MB/sec (Max.)           MTBF            > 3,000,000 hours
               4KB random read   36K IOPS (Max.)               Erase counts    Up to 60,000 times                 aSLC
               4KB random write  40K IOPS (Max.)               ECC             66 bits per 1024 bytes block
               Environmental                                   Physical specification
               Operating temp.  STD. 0˚C~+70˚C/IND. -40˚C~+85˚C    Weight (Max.)  100g
               Non-operating temp.  STD. -20˚C~+80˚C/IND. -50˚C~+95˚C    Dimension (WxLxH)  70.00 x 100.00 x 9.20 (mm)
               Humidity         10% ~ 95% non-condensing       Conformal coating  Optional
               Vibration        70 Hz to 2K Hz, 15G, 3 axes    Warranty
               Shock            0.5ms, 1500 G, 3 axes          SLC STD. grade  3 years or within 60,000 erasing counts
               Altitude         70,000 feet                    SLC IND. grade  5 years or within 60,000 erasing counts  MLC
               Part Number List
               Capacity               0ºC~+70ºC                 Capacity              -40ºC~+85ºC
                8GB             SR2SR008G-MSCTC-UFE(USE)P        8GB             WR2SR008G-MSITIUFE(USE)P
               16GB             SR2SR016G-MSCTC-UFE(USE)P        16GB            WR2SR016G-MSITIUFE(USE)P
               32GB             SR2SR032G-MSCTC-UFE(USE)P        32GB            WR2SR032G-MSITIUFE(USE)P
               64GB             SR2SR064G-MSCTC-UFE(USE)P        64GB            WR2SR064G-MSITIUFE(USE)P
               128GB            SR2SR128G-MSCTC-UFE(USE)P       128GB            WR2SR128G-MSITIUFE(USE)P           3D-NAND
               256GB            SR2SR256G-MSCTC-UFE(USE)P       256GB            WR2SR256G-MSITIUFE(USE)P

               Part Number Decoder
              X1   X2  X3   X4   X5   X6   X7   X8  X9   X10  X11  X12  X13  X14  X15  X16  X17  X18  X19  X20
             Example
              W    R    2    S   R    2    5    6    G        M    S    I    T    I    U    F   E    P    C        Module  DRAM

              X1  Grade                                      X13  Controller grade
             S : Standard grade operating temp. 0ºC~+70ºC    C : Commercial grade
             W: Industrial grade operating temp. -40ºC~+85ºC   I : Industrial grade
              X2  The material of casing                     X14  Flash IC brand
             R : Rugged metal casing                         T : Toshiba SLC-NAND flash IC                           Adapter
              X3   X4  X5  Product category                  X15  Flash IC grade
             2SR : 2.5” 9 mm height SATA III SSD with DRAM cache  C : Commercial grade
                                                              I : Industrial grade
              X6   X7  X8   X9  Capacity
                                                             X16  X17  X18  Special function
             008G : 8GB  064G : 64GB
             016G : 16GB  128G : 128GB                       UFE :  Fast Erase function only
             032G : 32GB  256G : 256GB                       USE :  Secure Erase function (supported by special firmware) &   Card-drive
                                                             Fast Erase function
             X11  Controller
                                                             X19  H/W Encryption
             M : HERCULES Series
             X12  Controller version                         P : Full-Drive Encryption
             A, B, C, D…..                                   X20  Reserved for specific requirements
                                                             C : Conformal coating (optional)






                                                            40
                                            Product specifications are subject to change without prior notice.
