B19026 HERCULES-PD Series Industrial SLC USB 2.0 Flash Disk Generation 4SB (G4SB)

 Features

 SLC-NAND flash technology
 IP-54 & IP-68 Waterproof metal casing design
 Rugged Metal Casing with screw threads to fix its cap
 Aluminum and electroplated in black
 Capacities from 128MB up to 8GB

 Specification
 Compatibility USB 2.0  Power consumption
 Declarations RoHS & REACH compliant  Power requirement 5V ± 10% via USB port
 Flash technology SLC-NAND flash technology  Reading mode 97.5 mA (Max.) SLC
 From-factor Pen drive  Writing mode 110 mA (Max.)
 Host interface 4 pins USB Type A connector  Idle mode 66.4 mA (Max.)
 Performance  Reliability
 Data transfer rate Hi-Speed up to 480 Mbps (60MB/s)  Wear-leveling Static wear-leveling algorithms
 Sequential read 31.5 MB/sec (Max.)  TBW Up to 56.1 TBW at 8GB Capacity
 Sequential write 24.5 MB/sec (Max.) (Client workload by JESD-219A)
 Environmental  MTBF > 3,000,000 hours
 Operating temp. STD. 0˚C~+70˚C/IND. -40˚C~+85˚C  Erase counts Up to 60,000 times aSLC
 Non-operating temp. STD. -20˚C~+80˚C/IND. -50˚C~+95˚C  ECC 72 bits per 1024 bytes block
 Humidity 10%~95% non-condensing  Physical specification
 Vibration 70 Hz to 2K Hz, 15G, 3 axes  Weight (Max.) 22g
 Shock 0.5ms, 1500G, 3 axes  Dimension (WxLxH) 15.95 x 54.82 x 15.95 (mm)
 Altitude 70,000 feet  Conformal coating Optional
 OS supported Windows series O.S.Linux,  Warranty
VxWorks and DOS  SLC STD. grade 3 years or within 60,000 erasing counts
 SLC IND. grade 5 years or within 60,000 erasing counts MLC
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
128MB SRUFD128M-MPDTC-4SB 128MB WRUFD128M-MPDTI-4SB
256MB SRUFD256M-MPDTC-4SB 256MB WRUFD256M-MPDTI-4SB
512MB SRUFD512M-MPDTC-4SB 512MB WRUFD512M-MPDTI-4SB
1GB SRUFD001G-MPDTC-4SB 1GB WRUFD001G-MPDTI-4SB
2GB SRUFD002G-MPDTC-4SB 2GB WRUFD002G-MPDTI-4SB
4GB SRUFD004G-MPDTC-4SB 4GB WRUFD004G-MPDTI-4SB 3D-NAND
8GB SRUFD008G-MPDTC-4SB 8GB WRUFD008G-MPDTI-4SB

 Part Number Decoder
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example
W R U F D 0 0 8 G M P D T I 4 S B C Module DRAM

X1 Grade X12 X13 Controller version
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..PD
W: Industrial grade operating temp. -40ºC~+85ºC
X14 Flash IC brand
X2 The material of casing
T : Toshiba SLC-NAND flash IC
R : Rugged metal casing Adapter
X15 Flash IC grade
X3 X4 X5 Product category
C : Commercial grade
UFD : USB Flash Disk I : Industrial grade
X6 X7 X8 X9 Capacity X17 X18 X19 Housing Generation
128M : 128MB 002G : 2GB 4SB : Generation 4 housing , Screw Thread Black
256M : 256MB 004G : 4GB
512M : 512MB 008G : 8GB X20 Reserved for specific requirements Card-drive
001G : 1GB C : Conformal coating (optional)
X11 Controller
M : HERCULES Series
