A19015 HERMES-J Series Industrial SLC mSATA III Half Size SSD (MSH)

 Features

 SLC-NAND flash technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support S.M.A.R.T. command set and utility
 Capacities from 4GB up to 32GB

 Specification
 Compatibility SATA Revision 3.1  Power consumption
SLC  Declarations RoHS & REACH compliant  Power requirement +3.3 V ± 5%
240mA (Max.)

Flash technology

Reading mode
SLC-NAND flash technology
 Form-factor mSATA mini form factor  Writing mode 240mA (Max.)
Compliant with JEDEC MO-300B  Idle mode 130mA (Max.)
 Host Interface mini PCI-e connector with 52 pins  Reliability
SATA pin out  Wear-leveling Static wear-leveling algorithms
 Performance  TBW Up to 192 TBW at 32GB Capacity
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s (Client workload by JESD-219A)
aSLC  Sequential read 220 MB/sec (Max.)  MTBF > 3,000,000 hours
Sequential write

Erase counts

Up to 60,000 times
120 MB/sec (Max.)
ECC

Environmental

40 bits per 1024 bytes block
 Operating temp. STD. 0˚C~+70˚C/IND. -40˚C~+85˚C  Physical specification
 Non-operating temp. STD. -20˚C~+80˚C/IND. -50˚C~+95˚C  Weight (Max.) 3.5g
 Humidity 10% ~ 95% non-condensing  Dimension (WxL) 29.80 x 26.80 (mm)
 Vibration 70 Hz to 2K Hz, 20G, 3 axes  Conformal coating Optional
 Shock 0.5ms, 1500 G, 3 axes  Warranty 3 years or within 60,000 erasing counts
70,000 feet

SLC STD. grade
Altitude

MLC  SLC IND. grade 5 years or within 60,000 erasing counts
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
4GB SBMSH004G-JJCTC-(T) 4GB WBMSH004G-JJITI-(T)
SBMSH008G-JJCTC-(T)
WBMSH008G-JJITI-(T)
8GB
8GB
3D-NAND  Part Number Decoder SBMSH016G-JJCTC-(T) 16GB WBMSH016G-JJITI-(T)
16GB
32GB
SBMSH032G-JJCTC-(T)
WBMSH032G-JJITI-(T)
32GB
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example B M S H 0 3 2 G J J I T I T C
W
DRAM Module X1 Grade X12 Controller version
S : Standard grade operating temp. 0ºC~+70ºC
W: Industrial grade operating temp. -40ºC~+85ºC A, B, C, D…..
X13 Controller grade
X2 The material of casing
C : Commercial grade
B : Bare (without casing)
I : Industrial grade
Adapter MSH : Mini SATA Module Half Size (mSATA mini) T : Toshiba SLC-NAND flash IC
Product category
Flash IC brand
X5
X4
X14
X3
Flash IC grade
X7
X6
X15
004G : 4GB X8 X9 Capacity C : Commercial grade
008G : 8GB
I : Industrial grade
Card-drive 032G : 32GB Blank : Standard product w/o thermal sensor and conformal-coating
016G : 16GB
X19
X20
Reserved for specific requirements
X18
X17
Controller
X11
T : Thermal Sensor (optional)
C : Conformal coating (optional)
J : HERMES Series
