A19058     HERMES-JI Series  MLC 1.8” Slim Lite SATA III SSD (8SJ)

                                                               Features

                                                                MLC-NAND flash technology
                                                                Support Trim command set
                                                                Support Native Command Queuing (NCQ)
                                                                Support S.M.A.R.T. command set and utility
                                                                Support Power Loss Protection
                                                                Capacities from 4GB up to 256GB
               Specification
               Compatibility    SATA Revision 3.1              Power consumption
                                 ATA-8 command set              Power requirement  +5 V ± 5%
               Declarations     RoHS & REACH compliant         Reading mode    306mA (Max.)                       SLC
               Flash technology  MLC-NAND flash technology      Writing mode    280mA (Max.)
               Form-factor      1.8" Slim Lite SATA III SSD JEDEC     Idle mode  151mA (Max.)
                                 MO-297A Specification compliance    Reliability
               Host Interface   SATA 7-pin (data) + 15-pin (power)    Wear-leveling  Static wear-leveling algorithms
               Performance                                     TBW             Up to 75 TBW at 256GB Capacity
               Data transfer rate  SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s               (Client workload by JESD-219A)
               Sequential read  420 MB/sec (Max.)              Erase counts    Up to 3,000 times
               Sequential write  140 MB/sec (Max.)             ECC             40 bits per 1024 bytes block       aSLC
               Environmental                                   Physical specification
               Operating temp.  STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C    Weight (Max.)  15g
               Non-operating temp.  STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C    Dimension (WxL)  54.00 x 39.00 (mm)
               Humidity         10% ~ 95% non-condensing       Conformal coating  Optional
               Vibration        70 Hz to 2K Hz, 20G, 3 axes    Warranty        2 years or within 3,000 erasing counts
               Shock            0.5ms, 1500 G, 3 axes
               Altitude         70,000 feet
               Part Number List                                                                                    MLC
               Capacity               0ºC~+70ºC                 Capacity              -40ºC~+85ºC
                4GB                SB8SJ004G-JJCTMB-(T)          4GB              WB8SJ004G-JJCTMB-(T)C
                8GB                SB8SJ008G-JJCTMB-(T)          8GB              WB8SJ008G-JJCTMB-(T)C
               16GB                SB8SJ016G-JJCTMB-(T)          16GB             WB8SJ016G-JJCTMB-(T)C
               32GB                SB8SJ032G-JJCTMB-(T)          32GB             WB8SJ032G-JJCTMB-(T)C
               64GB                SB8SJ064G-JICTMB-(T)          64GB             WB8SJ064G-JICTMB-(T)C
               128GB               SB8SJ128G-JICTMB-(T)         128GB             WB8SJ128G-JICTMB-(T)C             3D-NAND
               256GB               SB8SJ256G-JICTMB-(T)         256GB             WB8SJ256G-JICTMB-(T)C

            Notes : HERMES-J Series from 4GB to 32GB; HERMES-I Series from 64GB and 256GB
               Part Number Decoder
              X1   X2  X3   X4   X5   X6   X7   X8  X9   X10  X11  X12  X13  X14  X15  X16  X17  X18  X19  X20
             Example 1                                                                                             Module  DRAM
              W    B    8    S    J   0    3    2    G         J    J   C    T    M    B         T   C
             Example 2
              W    B    8    S    J   2    5    6    G         J    I   C    T    M    B         T   C

              X1  Grade                                      X13  Controller grade
             S : Standard grade operating temp. 0ºC~+70ºC    C : Commercial grade                                   Adapter
             W : Wide temp. grade operating temp. -40ºC~+85ºC
                                                             X14  Flash IC brand
              X2  The material of casing
                                                             T : Toshiba NAND flash IC
             B : Bare (without casing)
                                                             X15  Flash IC type
              X3   X4  X5  Product category                  M : MLC-NAND flash IC
             8SJ : 1.8” Slim Lite SATA III SSD
                                                             X16  MLC Technology
              X6   X7  X8   X9  Capacity                     B : Toshiba 15nm MLC                                   Card-drive
             004G : 4GB  064G : 64GB                         X18  X19  X20  Reserved for specific requirements
             008G : 8GB  128G : 128GB
             016G : 16GB  256G : 256GB                       Blank : Standard product w/o thermal sensor and conformal-coating
             032G : 32GB                                     T : Thermal Sensor (optional)
             X11  Controller                                 C : Conformal coating (optional)
             J : HERMES Series
             X12  Controller version
             A, B, C, D…..I,J...

                                                            78
                                            Product specifications are subject to change without prior notice.
