A19059 HERMES-JI Series MLC 2.5” 7mm Height SATA III SSD (7SF)

 Features

 MLC-NAND flash technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support S.M.A.R.T. command set and utility
 Support Power Loss Protection
 Capacities from 4GB up to 512GB
 Specification
 Compatibility SATA Revision 3.1  Power consumption
SLC  Declarations ATA-8 ACS2 command set  Power requirement +5V ± 5%
RoHS & REACH compliant
Reading mode
170 mA (Max.)

 Flash technology MLC-NAND flash technology  Writing mode 310mA (Max.)
 Form-factor Rugged Metal 2.5” 7mm height SATA SSD  Idle mode 60mA (Max.)
 Host Interface SATA 7-pin (data) + 15-pin (power)  Reliability
 Performance  Wear-leveling Static wear-leveling algorithms
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s  TBW Up to 153.6 TBW at 512GB Capacity
 Sequential read 422 MB/sec (Max.) (Client workload by JESD-219A)
aSLC  Sequential write 147 MB/sec (Max.)  Erase counts Up to 3,000 times
Environmental
40 bits per 1024 bytes block

ECC

Physical specification
Operating temp.

STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C

 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Weight (Max.) 50g
 Humidity 10% ~ 95% non-condensing  Dimension (WxLxH) 69.90 x 100.0 x 7.00 (mm)
 Vibration 70 Hz to 2K Hz, 20G, 3 axes  Conformal coating Optional
 Shock 0.5ms, 1500G, 3 axes  Warranty 2 years or within 3,000 erasing counts
 Altitude 70,000 feet
MLC  Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
Part Number List
4GB SR7SF004G-JJCTMB-(T) 4GB WR7SF004G-JJCTMB-(T)C
8GB SR7SF008G-JJCTMB-(T) 8GB WR7SF008G-JJCTMB-(T)C
16GB SR7SF016G-JJCTMB-(T) 16GB WR7SF016G-JJCTMB-(T)C
SR7SF032G-JJCTMB-(T)
32GB
WR7SF032G-JJCTMB-(T)C
32GB
3D-NAND 128GB SR7SF064G-JICTMB-(T) 128GB WR7SF064G-JICTMB-(T)C
64GB
64GB
SR7SF128G-JICTMB-(T)
WR7SF128G-JICTMB-(T)C
256GB
256GB
WR7SF256G-JICTMB-(T)C
SR7SF256G-JICTMB-(T)
512GB
WR7SF512G-JICTMB-(T)C
SR7SF512G-JICTMB-(T)
512GB
Notes : HERMES-J Series from 4GB to 32GB; HERMES-I Series from 64GB and 512GB
 Part Number Decoder
DRAM Module Example 1 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X1
X2
W
R
Example 2 7 S F 0 3 2 G J J C T M B T C
W R 7 S F 5 1 2 G J I C T M B T C
Adapter S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D …I, J…
Grade
X1
Controller version
X12
W : Wide temp. grade operating temp. -40ºC~+85ºC
X2 The material of casing X13 Controller grade
C : Commercial grade
R : Rugged metal casing
Card-drive 7SF : 2.5” 7 mm height SATA III SSD T : Toshiba NAND flash IC
Flash IC brand
X14
Product category
X5
X4
X3
Flash IC type
X15
Capacity
X7
X9
X6
X8
M : MLC-NAND flash IC
004G : 4GB
128G : 128GB
008G : 8GB 064G : 64GB X16 MLC Technology
016G : 16GB 256G : 256GB B : Toshiba 15nm MLC
032G : 32GB 512G : 512GB X18 X19 X20 Reserved for specific requirements
X11 Controller Blank : Standard product w/o thermal sensor and conformal-coating
J : HERMES Series T : Thermal Sensor (optional)
C : Conformal coating (optional)
79
