A19075 PHANES-K Series 3D-NAND mSATA III SSD (MSM)

 Features
 TOSHIBA BiCS Flash™ (3D-NAND) technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm
 Support S.M.A.R.T. command set and utility
 Support Power Loss Protection
 Capacities from 64GB up to 512GB
 Specification
 Compatibility SATA Revision 3.2  Power consumption
SLC  Declarations ATA-8 ACS4 command set  Power requirement +3.3 V ± 5%
RoHS & REACH compliant
Reading mode
1,500 mW (Max.)

 Flash technology 3D-NAND flash technology  Writing mode 1,550 mW (Max.)
 Form-factor Standard mSATA form factor  Idle mode 330 mW (Max.)
Compliant with JEDEC MO-300A  Reliability
 Host Interface mini PCI-e connector with 52 pins  Wear-leveling Static and Dynamic wear-leveling algorithms
SATA pin out  TBW Up to 425 TBW at 512GB Capacity.
 Performance (Client workload by JESD-219A)
aSLC  Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s  Erase counts Up to 3,000 times
550 MB/sec (Max.)
ECC


Sequential read
LDPC (Low Density Parity Check)

Sequential write
Physical specification

490 MB/sec (Max.)
 Environmental  Weight (Max.) 8g
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Dimension (WxL) 29.85 x 50.80 (mm)
 Non-operating temp STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Conformal coating Optional
 Humidity 10% ~ 95% non-condensing  Warranty 2 years or within 3,000 erasing counts
 Vibration 80 Hz to 2K Hz, 20G, 3axes
0.5ms, 1500G, 3 axes
Shock

MLC  Altitude 70,000 feet
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
64GB
64GB SBMSM064G-PKCT3-(W/T/WT) 128GB WBMSM064G-PKCT3-(W/T/WT)C
SBMSM128G-PKCT3-(W/T/WT)
WBMSM128G-PKCT3-(W/T/WT)C
128GB
3D-NAND  Part Number Decoder SBMSM256G-PKCT3-(W/T/WT) 256GB WBMSM256G-PKCT3-(W/T/WT)C
256GB
512GB
WBMSM512G-PKCT3-(W/T/WT)C
SBMSM512G-PKCT3-(W/T/WT)
512GB
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example B M S M 5 1 2 G P K C T 3 W T C
W
DRAM Module X1 Grade X12 Controller version
S : Standard grade operating temp. 0ºC~+70ºC
W : Wide temp. grade operating temp. -40ºC~+85ºC A, B, C, D…..
X13 Controller grade
X2 The material of casing
C : Commercial grade
Adapter MSM : Mini SATA Module (mSATA) T : Toshiba NAND flash IC
B : Bare (without casing)
X14
Flash IC brand
Product category
X5
X4
X3
Flash IC type
X15
X7
X6
064G : 64GB X8 X9 Capacity 3 : BiCS 3D-NAND Flash IC Reserved for specific requirements
X17
X19
X18
X20
128G : 128GB
Card-drive 256G : 256GB W : Write Protection Switch (optional)
Blank : Standard product w/o thermal sensor and conformal-coating
512G : 512GB
T : Thermal Sensor (optional)
Controller
X11
WT : Write Protection Switch + Thermal Sensor (optional)
C : Conformal coating (optional)
P : PHANES Series
97
Product specifications are subject to change without prior notice.
