A19077 PHANES-K Series 3D-NAND mSATA III Half Size SSD (MSH)

 Features
 TOSHIBA BiCS Flash™ (3D-NAND) technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm
 Support S.M.A.R.T. command set and utility
 Support Power Loss Protection
 Capacities from 32GB up to 128GB
 Specification
 Compatibility SATA Revision 3.2  Power consumption
SLC  Declarations ATA-8 ACS4 command set  Power requirement +3.3 V ± 5%

RoHS & REACH compliant
1,200 mW (Max.)
Reading mode
 Flash technology 3D-NAND flash technology  Writing mode 1,330 mW (Max.)
 Form-factor mSATA mini form factor  Idle mode 300 mW (Max.)
Compliant with JEDEC MO-300B  Reliability
 Host Interface mini PCI-e connector with 52 pins SATA pin out  Wear-leveling Static and Dynamic wear-leveling algorithms
 Performance  TBW Up to 75 TBW at 128GB Capacity
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s (Client workload by JESD-219A)
aSLC  Sequential read 550 MB/sec (Max.)  Erase counts Up to 3,000 times


LDPC (Low Density Parity Check)
ECC
450 MB/sec (Max.)
Sequential write

Environmental

Physical specification
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Weight (Max.) 3.5g
 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Dimension (WxL) 29.85 x 26.80 (mm)
 Humidity 10% ~ 95% non-condensing  Conformal coating Optional
 Vibration 80 Hz to 2K Hz, 20G, 3axes  Warranty 2 years or within 3,000 erasing counts
 Shock 0.5ms, 1500 G, 3 axes

Altitude
70,000 feet
MLC  Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
32GB SBMSH032G-PKCT3 32GB WBMSH032G-PKCT3-C
64GB
64GB SBMSH064G-PKCT3 128GB WBMSH064G-PKCT3-C
128GB
WBMSH128G-PKCT3-C
SBMSH128G-PKCT3
3D-NAND  Part Number Decoder X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X1
X3
X2
X4
Example
W B M S H 1 2 8 G P K C T 3 C
Controller version
Grade
X1
X12
DRAM Module S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..
W : Wide temp. grade operating temp. -40ºC~+85ºC
Controller grade
X13
X2
The material of casing
C : Commercial grade
B : Bare (without casing)
X14 Flash IC brand
X3 X4 X5 Product category T : Toshiba NAND flash IC
Adapter MSH : Mini SATA Module Half Size (mSATA mini) 3 : BiCS 3D-NAND Flash IC
Flash IC type
X15
Capacity
X7
X8
X9
X6
032G : 32GB
064G : 64GB X17 X18 X19 X20 Reserved for specific requirements
128G : 128GB C : Conformal coating (optional)
Controller
Card-drive P : PHANES Series
X11
