A20097 PHANES-LT Series 3D-NAND 2.5” 7mm Height SATA III SSD Supports Power Interrupts Data Protection (7ST) NEW!

 Features
 TOSHIBA BiCS Flash™ (3D-NAND) technology
 Power interrupt data protection via tantalum capacitors
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm
 Support S.M.A.R.T. command set and utility
 Ultra-high random read/write speed
 Capacities from 512GB up to 4TB
 Specification
 Compatibility SATA Revision 3.2  Power consumption
ATA-8 ACS4 command set  Power requirement +5V ± 5%
 Declarations RoHS & REACH compliant  Reading mode 3,200 mW (Max.) SLC
 Flash technology 3D-NAND flash technology  Writing mode 4,000 mW (Max.)
 Form-factor Rugged Metal 2.5” 7mm height SATA SSD  Idle mode 1,600 mW (Max.)
 Host Interface SATA 7-pin (data) + 15-pin (power)  Reliability
 Performance  Wear-leveling Static wear-leveling algorithms
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s  TBW Up to 7,353 TBW at 4TB Capacity
 Sequential read 550 MB/sec (Max.) (Client workload by JESD-219A)
 Sequential write 520 MB/sec (Max.)  Erase counts Up to 3,000 times
 4KB random read 77K IOPS (Max.)  ECC LDPC (Low Density Parity Check) aSLC
 4KB random write 71K IOPS (Max.)  Physical specification
 Environmental  Weight (Max.) 50g
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Dimension (WxLxH) 69.90 x 100.00 x 7.00 (mm)
 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Conformal coating Optional
 Humidity 10% ~ 95% non-condensing  Warranty 2 years or within 3,000 erasing counts
 Vibration 80 Hz to 2K Hz, 20G, 3 axes
 Shock 0.5ms, 1500G, 3 axes
 Altitude 70,000 feet MLC
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
512GB SR7ST512G-PLCT3 512GB WR7ST512G-PLCT3-C
1TB SR7ST001T-PLCT3 1TB WR7ST001T-PLCT3-C
2TB SR7ST002T-PLCT3 2TB WR7ST002T-PLCT3-C
4TB SR7ST004T-PLCT3 4TB WR7ST004T-PLCT3-C 3D-NAND

 Part Number Decoder
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example
W R 7 S T 0 0 4 T P L C T 3 C

X1 Grade X12 Controller version Module DRAM
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..
W : Wide temp. grade operating temp. -40ºC~+85ºC
X13 Controller grade
X2 The material of casing
C : Commercial grade
R : Rugged metal casing
X14 Flash IC brand
X3 X4 X5 Product category
T : Toshiba NAND flash IC Adapter
7ST : 2.5” 7mm height SATA III SSD with Tantalum Capacitors
X15 Flash IC type
X6 X7 X8 X9 Capacity (Notice)
3 : BiCS 3D-NAND Flash IC
512G : 480GB 002T : 1,920GB X17 X18 X19 X20 Reserved for specific requirements
001T : 960GB 004T : 3,840GB
C : Conformal coating (optional)
X11 Controller
P : PHANES Series Card-drive

106
Product specifications are subject to change without prior notice.
