A20094 MUSE-ER Series 3D-NAND 1.8” Slim Lite SATA III SSD w/DRAM (8RJ) NEW!

 Features

 TOSHIBA BiCS FlashTM (3D-NAND) technology
 Built with DDRIII SDRAM cache
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support S.M.A.R.T. command set and utility
 Capacities from 128GB up to 512GB
 Specification
 Compatibility SATA Revision 3.2  Power consumption
ATA-8 ACS4 command set  Power requirement +5 V ± 5%
 Declarations RoHS & REACH compliant  Reading mode 419mA (Max.) SLC
 Flash technology 3D-NAND flash technology  Writing mode 543mA (Max.)
 Form-factor 1.8" Slim Lite SATA III SSD JEDEC  Idle mode 181mA (Max.)
MO-297A Specification compliance  Reliability
 Host Interface SATA 7-pin (data) + 15-pin (power)  Wear-leveling Static wear-leveling algorithms
 Performance  TBW Up to 600 TBW at 512GB Capacity
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s (Sequential Write)
 Sequential read 560 MB/sec (Max.)  Erase counts Up to 3,000 times
 Sequential write 520 MB/sec (Max.)  ECC LDPC (Low Density Parity Check) aSLC
 4KB random read 73K IOPS (Max.)  Physical specification
 4KB random write 65K IOPS (Max.)  Weight (Max.) 15g
 Environmental  Dimension (WxL) 54.00 x 39.00 (mm)
 Operating temp. STD. 0˚C~+70˚C/IND. -40˚C~+85˚C  Conformal coating Optional
 Non-operating temp. STD. -20˚C~+80˚C/IND. -50˚C~+95˚C  Warranty 2 years or within 3,000 erasing counts
 Humidity 10% ~ 95% non-condensing
 Vibration 70 Hz to 2K Hz, 20G, 3 axes
 Shock 0.5ms, 1500 G, 3 axes MLC
 Altitude 70,000 feet
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
128GB SB8RJ128G-VECT3-(T) 128GB WB8RJ128G-VECT3-(T)C
256GB SB8RJ256G-VECT3-(T) 256GB WB8RJ256G-VECT3-(T)C
512GB SB8RJ512G-VECT3-(T) 512GB WB8RJ512G-VECT3-(T)C 3D-NAND

 Part Number Decoder
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example
W B 8 R J 5 1 2 G V E C T 3 T C

X1 Grade X12 Controller version Module DRAM
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..
W: Wide temp. grade operating temp. -40°C~+85°C
X13 Controller grade
X2 The material of casing
C : Commercial grade
B : Bare (without casing)
X14 Flash IC brand
X3 X4 X5 Product category
T : Toshiba NAND flash IC Adapter
8RJ : 1.8” Slim Lite SATA III SSD with DRAM cache
X15 Flash IC grade
X6 X7 X8 X9 Capacity
3: BiCS 3D-NAND Flash IC
128G : 128GB 512G : 512GB X17 X18 X19 X20 Reserved for specific requirements
256G : 256GB
Blank : Standard product w/o thermal sensor and conformal-coating
X11 Controller T : Thermal Sensor (optional)
V : MUSE Series C : Conformal coating (optional) Card-drive

102
Product specifications are subject to change without prior notice.
