A19075 PHANES-K Series 3D-NAND mSATA III SSD (MSM)

 Features
 TOSHIBA BiCS Flash™ (3D-NAND) technology
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm
 Support S.M.A.R.T. command set and utility
 Support Power Loss Protection
 Capacities from 64GB up to 1TB
 Specification
 Compatibility SATA Revision 3.2  Power consumption
SLC  Declarations ATA-8 ACS4 command set  Power requirement +3.3 V ± 5%
Reading mode

RoHS & REACH compliant
1,600 mW (Max.)
 Flash technology 3D-NAND flash technology  Writing mode 1,650 mW (Max.)
 Form-factor Standard mSATA form factor  Idle mode 330 mW (Max.)
Compliant with JEDEC MO-300A  Reliability
 Host Interface mini PCI-e connector with 52 pins  Wear-leveling Static and Dynamic wear-leveling algorithms
SATA pin out  TBW Up to 835 TBW at 1TB Capacity.
 Performance (Client workload by JESD-219A)
aSLC  Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s  Erase counts Up to 3,000 times
550 MB/sec (Max.)
Sequential read

ECC

LDPC (Low Density Parity Check)
Sequential write
500 MB/sec (Max.)
Physical specification


 Environmental  Weight (Max.) 8g
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Dimension (WxL) 29.85 x 50.80 (mm)
 Non-operating temp STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Conformal coating Optional
 Humidity 10% ~ 95% non-condensing  Warranty 2 years or within 3,000 erasing counts
 Vibration 80 Hz to 2K Hz, 20G, 3axes
0.5ms, 1500G, 3 axes

Shock
MLC  Altitude 70,000 feet
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
64GB
64GB SBMSM064G-PKCT3-(W/T/WT) 128GB WBMSM064G-PKCT3-(W/T/WT)C
128GB
SBMSM128G-PKCT3-(W/T/WT)
WBMSM128G-PKCT3-(W/T/WT)C
3D-NAND 256GB SBMSM256G-PKCT3-(W/T/WT) 256GB WBMSM256G-PKCT3-(W/T/WT)C
SBMSM512G-PKCT3-(W/T/WT)
WBMSM512G-PKCT3-(W/T/WT)C
512GB
512GB
SBMSM001T-PKCT3-(W/T/WT)
1TB
1TB
WBMSM001T-PKCT3-(W/T/WT)C

X1 Part Number Decoder X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X3
X4
X2
Example
DRAM Module W Grade M S M 0 0 1 T X12 Controller version T 3 W T C
P
B
C
K
X1
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..
W : Wide temp. grade operating temp. -40ºC~+85ºC
X13 Controller grade
X2 The material of casing C : Commercial grade
Adapter B : Bare (without casing) T : Toshiba NAND flash IC
X14
Flash IC brand
Product category
X3
X4
X5
MSM : Mini SATA Module (mSATA)
Flash IC type
X15
X6 X7 X8 X9 Capacity 3 : BiCS 3D-NAND Flash IC Reserved for specific requirements
064G : 64GB
Card-drive 128G : 128GB Blank : Standard product w/o thermal sensor and conformal-coating
X17
X18
X19
X20
256G : 256GB
W : Write Protection Switch (optional)
512G : 512GB
T : Thermal Sensor (optional)
001T : 1TB
WT : Write Protection Switch + Thermal Sensor (optional)
Controller
X11
P : PHANES Series C : Conformal coating (optional)
97 Updated on 200519-01
Product specifications are subject to change without prior notice.
