A19082 MUSE-ET Series 3D-NAND 2.5” 7mm Height SATA III SSD Supports Power Interrupts Data Protection (7ST)

 Features
 TOSHIBA BiCS Flash™ (3D-NAND) technology
 Power interrupt data protection via tantalum capacitors
 Support Trim command set
 Support Native Command Queuing (NCQ)
 Support LDPC (Low Density Parity Check) ECC algorithm
 Support S.M.A.R.T. command set and utility
 Ultra-high random read/write speed
 Capacities from 128GB up to 2TB
 Specification
 Compatibility SATA Revision 3.2  Power consumption
SLC  Declarations ATA-8 ACS4 command set  Power requirement +5V ± 5%
Reading mode
RoHS & REACH compliant
480 mA (Max.)

 Flash technology 3D-NAND flash technology  Writing mode 620 mA (Max.)
 Form-factor Rugged Metal 2.5” 7mm height SATA SSD  Idle mode 190 mA (Max.)
 Host Interface SATA 7-pin (data) + 15-pin (power)  Reliability
 Performance  Wear-leveling Static wear-leveling algorithms
 Data transfer rate SATA 1.5Gb/s, 3.0Gb/s, 6.0Gb/s  TBW Up to 2,344 TBW at 2TB Capacity
 Sequential read 550 MB/sec (Max.) (Client workload by JESD-219A)
aSLC  Sequential write 475 MB/sec (Max.)  Erase counts Up to 3,000 times

LDPC (Low Density Parity Check)
87K IOPS (Max.)
ECC
4KB random read


Physical specification

66K IOPS (Max.)
4KB random write
 Environmental  Weight (Max.) 65g
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  Dimension (WxLxH) 69.90 x 100.00 x 7.00 (mm)
 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Conformal coating Optional
 Humidity 10% ~ 95% non-condensing  Warranty 2 years or within 3,000 erasing counts
 Vibration 70 Hz to 2K Hz, 20G, 3 axes
Shock

0.5ms, 1500G, 3 axes
MLC  Altitude 70,000 feet
 Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
128GB SR7ST128G-VECT3 128GB WR7ST128G-VECT3-C
256GB
256GB
SR7ST256G-VECT3
WR7ST256G-VECT3-C
3D-NAND 512GB SR7ST512G-VECT3 512GB WR7ST512G-VECT3-C
WR7ST001T-VECT3-C
SR7ST001T-VECT3
1TB
1TB
2TB
SR7ST002T-VECT3
2TB
WR7ST002T-VECT3-C

X1 Part Number Decoder X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X3
X4
X2
Example
DRAM Module W Grade 7 S T 0 0 2 T V Controller version T 3 C
E
R
C
X12
X1
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..
W : Wide temp. grade operating temp. -40ºC~+85ºC
X13 Controller grade
X2 The material of casing C : Commercial grade
Adapter R : Rugged metal casing T : Toshiba NAND flash IC
X14
Flash IC brand
X4
Product category
X5
X3
7ST : 2.5” 7mm height SATA III SSD with Tantalum Capacitors
X6 X7 X8 X9 Capacity X15 Flash IC type
3 : BiCS 3D-NAND Flash IC Reserved for specific requirements
128G : 128GB
001T : 1TB
Card-drive 256G : 256GB 002T : 2TB C : Conformal coating (optional)
X20
X17
X19
X18
512G : 512GB
Controller
X11
V : MUSE Series
105
Product specifications are subject to change without prior notice.
