A19041 PHANES-F Series aSLC SDHC & SDXC Memory Card SD3.0 (SDH/SDX)

 Features
 Enhanced MLC-NAND flash by sophisticated aSLC firmware
 Support SD mode and SPI mode
 Support CPRM
 Support UHS-1
 Write Protect switch
 Support S.M.A.R.T. command set and utility
 Capacities from 4GB up to 128GB

 Compatibility SDA3.0  Humidity 10% ~ 95% non-condensing
SLC  SDHC 4GB to 32GB: FAT16 file system  Vibration 80 Hz to 2K Hz, 20G, 3axes
Shock
SDXC


0.5ms, 1500G, 3 axes
64GB to 128GB: exFAT
 Declaration RoHS & REACH compliant  Altitude 70,000 feet
 Flash technology MLC-NAND flash technology  Power consumption
 Form-factor Standard SD card form-factor  Power requirement +3.3V ± 10%
 Host interface 9-pin connector  Reading mode 400 mA (Max.)
 Write Protection Mechanical switch  Writing mode 400 mA (Max.)
 Performance  Idle (Standby) mode 1000 uA (Max.)
aSLC  Data transfer rate Class-10  Reliability Static and Dynamic wear-leveling algorithms
Wear-leveling

SDHC: 99.5 MB/sec (Max.)
Sequential read

SDXC: 99.8 MB/sec (Max.)
Up to 20,000 times
Erase counts

 Sequential write SDHC: 92.7 MB/sec (Max.)  ECC BCH ECC
SDXC: 93.5 MB/sec (Max.)  Physical specification
 Environmental  Weight (Max.) 2.5g
 Operating temp. Wide Temp. -40˚C~+85˚C  Dimension (WxLxH) 24.0 x 32.0 x 2.1 (mm)
 Non-operating temp. Wide Temp. -50˚C~+95˚C  Warranty 2 years or within 20,000 erasing counts
MLC  Part Number List SDHC memory card SDXC memory card
Capacity -40ºC~+85ºC Capacity -40ºC~+85ºC
4GB WPSDH004G-PFITMBAS 64GB WPSDX064G-PFITMBAS
8GB WPSDH008G-PFITMBAS 128GB WPSDX128G-PFITMBAS
WPSDH016G-PFITMBAS
16GB
3D-NAND  Part Number Decoder WPSDH032G-PFITMBAS
32GB
X1
X2
Example 1 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
W P S D H 0 3 2 G P F I T M B A S
Example 2
DRAM Module W P S D X 1 2 8 G P F I T M B A S

X1 Grade X13 Controller grade
W : Wide temp grade operating temp. -40ºC~+85ºC I : Industrial grade
X2 The material of casing X14 Flash IC brand
Adapter P : Plastic casing X5 Product category T : Toshiba NAND flash IC

Flash IC type
X3
X4
X15
SDH : SDHC memory card
SDX : SDXC memory card M : MLC-NAND flash IC
X16 MLC Technology
Capacity
X9
X6 X7 X8 032G : 32GB B : Toshiba 15nm MLC
Card-drive 008G : 8GB 064G : 64GB AS : aSLC Technology extends MLC products’ lifespan
004G : 4GB
aSLC Technology
X17
X18
128G : 128GB
016G : 16GB
Reserved for specific requirements
X20
X19
Controller
X11
P : PHANES Series
X12 Controller version
A, B, C, D…..
59
Product specifications are subject to change without prior notice.
