Page 24 - APRO_2019_Catalog

A19003 HERMIT-A Series Industrial SLC CompactFlash ® Card Supports Write Protect Function (CFW)

 Features

 SLC-NAND flash technology
 Support PC Card Memory mode or True IDE mode
 Support write protect via a switch
 Support S.M.A.R.T. command set and utility
 Support C.H.S./LBA customization
 Capacities from 16MB up to 4GB
 Specification
 Compatibility CompactFlash® specification 3.0  Power requirement +5V ± 10% / + 3.3V ± 10%
SLC  Declarations Compatible with ATA/ATAPI-6  Reading mode 168.9 mA (Max.)
151.5 mA (Max.)
Writing mode

RoHS & REACH compliant
 Flash technology SLC-NAND flash technology  Idle mode 2.4 mA (Max.)
 Form-factor CompactFlash® type I  Reliability
 Host Interface Female 50 pins  Wear-leveling Static wear-leveling algorithms
 Performance  TBW Up to 210.9 TBW at 4GB Capacity
 Data transfer rate PIO 0~6, MWDMA 0~2, UDMA 0~4 (Sequential Write)
 Sequential read 36.4 MB/sec (Max.)  MTBF > 3,000,000 hours
aSLC  Sequential write 26.5 MB/sec (Max.)  Erase counts Up to 60,000 times

4 bits per 512 bytes block
Environmental

ECC

Operating temp.
Physical specification
STD. 0˚C~+70˚C/IND. -40˚C~+85˚C

 Non-operating temp. STD. -20˚C~+80˚C/IND. -50˚C~+95˚C  Weight (Max.) Plastic frame : 12g
 Humidity 10% ~ 95% non-condensing  Dimension (WxLxH) 42.8 x 36.4 x 3.3 (mm)
 Vibration 70 Hz to 2K Hz, 20G, 3 axes  Conformal coating Optional
 Shock 0.5ms, 1,500 G, 3 axes  Warranty
 Altitude 70,000 feet  SLC STD. grade 3 years or within 60,000 erasing counts
5 years or within 60,000 erasing counts
Power consumption

SLC IND. grade

MLC  Part Number List
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
16MB SPCFW016M-HACTC-UF 16MB WPCFW016M-HAITI-UF
32MB SPCFW032M-HACTC-UF 32MB WPCFW032M-HAITI-UF
WPCFW064M-HAITI-UF
64MB
SPCFW064M-HACTC-UF
64MB
3D-NAND 128MB SPCFW128M-HACTC-UF 128MB WPCFW128M-HAITI-UF
WPCFW256M-HAITI-UF
256MB
256MB
SPCFW256M-HACTC-UF
512MB
512MB
SPCFW512M-HACTC-UF
WPCFW512M-HAITI-UF
WPCFW001G-HAITI-UF
SPCFW001G-HACTC-UF
1GB
1GB
2GB
4GB SPCFW002G-HACTC-UF 2GB WPCFW002G-HAITI-UF
WPCFW004G-HAITI-UF
4GB
SPCFW004G-HACTC-UF
 Part Number Decoder
DRAM Module Example X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X1
H
C
F
I
U
I
A
T
C
W
P
0
4
G
0
F
W
Controller grade
X1 Grade C : Commercial grade
X13
S : Standard grade operating temp. 0ºC~+70ºC
Adapter W: Industrial grade operating temp. -40ºC~+85ºC I : Industrial grade
Flash IC brand
X14
The material of casing
X2
P : Plastic frame
X3 X4 X5 Product category T : Toshiba SLC-NAND flash IC
Flash IC grade
X15
CFW : CompactFlash® Card supports write protection C : Commercial grade
Card-drive 016M : 16MB X8 512M : 512MB PF : Optional as PIO-6 mode / Fixed disk type
I : Industrial grade
Capacity
X7
X6
X9
Data transfer rate / Disk types
X18
X17
032M : 32MB
001G : 1GB
002G : 2GB
064M : 64MB
PR : Optional as PIO-6 mode / Removable disk type
128M : 128MB
256M : 256MB 004G : 4GB UF : Defaulted as UDMA-4 mode / Fixed disk type
UR : Optional as UDMA-4 mode / Removable disk type
X11 Controller AA : Optional as Autosense UDMA or PIO mode /
Autosense removable disk type or fixed disk type
H : HERMIT Series
X19 X20 Reserved for specific requirements
X12 Controller version
C : Conformal coating (optional)
A, B, C, D…..
17
Product specifications are subject to change without prior notice.
