B19068 HERCULES-PD Series MLC USB 2.0 Flash Disk Generation 4SB (G4SB)

 Features

 MLC-NAND flash technology
 IP-54 & IP-68 Waterproof metal casing design
 Rugged Metal Casing with screw threads to fix its cap
 Aluminum and electroplated in black
 Capacities from 4GB up to 32GB

 Specification
 Compatibility USB 2.0  Power consumption
 Declarations RoHS & REACH compliant  Power requirement 5V ± 10% via USB port
 Flash technology MLC-NAND flash technology  Reading mode 95.5 mA (Max.) SLC
 From-factor Pen drive  Writing mode 99 mA (Max.)
 Host interface 4 pins USB Type A connector  Idle mode 62.8 mA (Max.)
 Performance  Reliability
 Data transfer rate Hi-Speed up to 480 Mbps (60MB/s)  Wear-leveling Static wear-leveling algorithms
 Sequential read 26 MB/sec (Max.)  TBW Up to 7.7 TBW at 32GB Capacity
 Sequential write 14.9 MB/sec (Max.) (Client workload by JESD-219A)
 Environmental  Erase counts Up to 3,000 times
 Operating temp. STD. 0˚C~+70˚C/W.T. -40˚C~+85˚C  ECC 72 bits per 1024 bytes block aSLC
 Non-operating temp. STD. -20˚C~+80˚C/W.T. -50˚C~+95˚C  Physical specification
 Humidity 10%~95% non-condensing  Weight (Max.) 22g
 Vibration 70 Hz to 2K Hz, 15G, 3 axes  Dimension (WxLxH) 15.95 x 54.82 x 15.95 (mm)
 Shock 0.5ms, 1500G, 3 axes  Conformal coating Optional
 Altitude 70,000 feet  Warranty 2 years or within 3,000 erasing counts
 OS supported Windows series O.S.Linux,
VxWorks and DOS
 Part Number List MLC
Capacity 0ºC~+70ºC Capacity -40ºC~+85ºC
4GB SRUFD004G-MPDTM-4SB 4GB WRUFD004G-MPDTM-4SBC
8GB SRUFD008G-MPDTM-4SB 8GB WRUFD008G-MPDTM-4SBC
16GB SRUFD016G-MPDTM-4SB 16GB WRUFD016G-MPDTM-4SBC
32GB SRUFD032G-MPDTM-4SB 32GB WRUFD032G-MPDTM-4SBC

 Part Number Decoder 3D-NAND
X1 X2 X3 X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
Example
W R U F D 0 3 2 G M P D T M 4 S B C

X1 Grade X12 X13 Controller version Module DRAM
S : Standard grade operating temp. 0ºC~+70ºC A, B, C, D…..PD
W : Wide temp. grade operating temp. -40ºC~+85ºC
X14 Flash IC brand
X2 The material of casing
T : Toshiba NAND flash IC
R : Rugged metal casing
X15 Flash IC type
X3 X4 X5 Product category
M : MLC-NAND flash IC
UFD : USB Flash Disk Adapter
X17 X18 X19 Housing Generation
X6 X7 X8 X9 Capacity
4SB : Generation 4 housing , Screw Thread Black
004G : 4GB 016G : 16GB
008G : 8GB 032G : 32GB X20 Reserved for specific requirements
X11 Controller C : Conformal coating (optional)
M : HERCULES Series Card-drive

88
Product specifications are subject to change without prior notice.
