A19091 Adapter & Reader Industrial 2.5” Form-factor SATA I to CF Card Adapter Series

 Features

 2.5” adapter with or without bracket or with 3.5” casing
 CF type II socket to SATA 1.0a
 7-pin SATA connector
 With a 4-pin power connector
 Bootable

 Specification
 SATA / ATA standard Compliant with serial ATA 1.0a specification  LED Indicator Optional for special request, 1 access LED
SLC Compliant with ultra ATA /66 (UDMA-4)  Bootable and 1 active LED
Yes
Integrated serial ATA link and PHY logic
 Form-factor 2.5” form-factor with 4 standard 2.5” HDD  Hot Swappable No
Fixed holes  Operation Voltage +5V
Optional with rear bracket  Environmental
Optional with 3.5" floppy size casing  Operating Temperature 0°C~+70°C
 Declaration RoHS & REACH compliant  Non-operating Temperature -20°C~+80°C
 Host interface SATA 7-pin female connector  Relative Humidity Max 90%
aSLC  CF Socket Serial ATA to parallel ATA device  Supported OS DOS, Windows, Linux and O.S.
CompactFlash® type II socket with ejector
Dimension

70.0 x 79.7 x 10.7 (mm)
With or without bracket
Support CF Card type
CompactFlash® card type I/II and MicroDrive 

 Power Connector 4-pin floppy power connector  3.5” Drive Casing 101.6 x 109.6 x 25.4 (mm)
 Data Transfer Mode Support PIO-4 mode, MWDMA-2 mode  Weight (Max.)
and up to UDMA-6 mode  Without bracket 30g
 Performance Support SATA generation 1 with transfer  Without bracket 36g
rate 1.5Gb/sec  3.5” Drave Casing 250g
1 year

Warranty
MLC  Part Number List
 AD-CF125SATA1003R Industrial 2.5" SATA I to CF adapter
 AD-CF12RSATA1003R Industrial 2.5" SATA I to CF adapter with rear bracket
 AD-CF123SATA1003R Industrial 2.5" SATA I to CF adapter with standard 3.5" drive bay
3D-NAND  Part Number Decoder X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16 X17 X18 X19 X20
X1
X2
X4
Example 1
A D C F 1 2 5 S A T A 1 0 0 3 R
Example 2 C F 1 2 R S A T A 1 0 0 3 R
D
A
DRAM Module Example 3 C F 1 2 3 S A T A 1 0 0 3 R
A
D

X1 X2 Adapter X9 X10 X11 X12 X13 Host interface
AD : Adapter series IDE04 : 40-pin IDE connector + 44-pin IDE connector
SATA 1 : SATA I 1.0a
Adapter CF : CompactFlash® card SATA 2 : SATA I 1.0a and SATA II 2.0
X4
Slot for card type
X5
SATA 3 : SATA I 1.0a & SATA II 2.0 & SATA III 3.0
CA : CFast™ card
APRO Internal code
X16
X15
X14
Slot number and type
X6
X7
X17 RoHS compliant
11 : 1 slot of CompactFlash® type I
12 : 1 slot of CompactFlash® type II R : RoHS compliant
Card-drive 5 : 2.5 form-factor
24 : 2 slots of CompactFlash® type II
Adapter form-factor
X8
3 : 2.5 form-factor w/ standard 3.5" drive casing
R : 2.5 form-factor w/ rear metal bracket

117
Product specifications are subject to change without prior notice.
